SOSA aligned power supplies

The Vicor SOSA-aligned power supply is a COTs power supply that is designed for 3U Open VPX systems that are developed to the SOSA standard. The module utilizes Vicor proprietary technology to enable high efficiency and power density for this highly rugged, conduction-cooled model.

Up to four power supplies can be paralleled to increase output power capability of +12V main and +3.3V auxiliary outputs with proprietary wireless current sharing. Need for conventional current‑share pins are eliminated. Current share accuracy is ±2A.

Select a SOSA Power Supply

0 製品

Part Number	Nominal Input (V)	Power (W)	Form-Factor	Conformal Coated	Output Voltage Config.	カートに入れる/詳細を見る
SOS028H3U800C000	Part Number: SOS028H3U800C000	Nominal Input (V): 18 – 45	Power (W): 800	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U800D000	Part Number: SOS028H3U800D000	Nominal Input (V): 18 – 45	Power (W): 800	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U800C001	Part Number: SOS028H3U800C001	Nominal Input (V): 18 – 45	Power (W): 800	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U800D001	Part Number: SOS028H3U800D001	Nominal Input (V): 18 – 45	Power (W): 800	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, VITA46 No-Key Guide Socket	詳細
SOS028H3U151C000	Part Number: SOS028H3U151C000	Nominal Input (V): 10 – 45	Power (W): 150	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U151D000	Part Number: SOS028H3U151D000	Nominal Input (V): 10 – 45	Power (W): 150	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U151C001	Part Number: SOS028H3U151C001	Nominal Input (V): 10 – 45	Power (W): 150	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U151D001	Part Number: SOS028H3U151D001	Nominal Input (V): 10 – 45	Power (W): 150	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U300C000	Part Number: SOS028H3U300C000	Nominal Input (V): 18 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U300D000	Part Number: SOS028H3U300D000	Nominal Input (V): 18 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U300C001	Part Number: SOS028H3U300C001	Nominal Input (V): 18 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U300D001	Part Number: SOS028H3U300D001	Nominal Input (V): 18 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U301C000	Part Number: SOS028H3U301C000	Nominal Input (V): 10 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U301D000	Part Number: SOS028H3U301D000	Nominal Input (V): 10 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U301C001	Part Number: SOS028H3U301C001	Nominal Input (V): 10 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U301D001	Part Number: SOS028H3U301D001	Nominal Input (V): 10 – 45	Power (W): 300	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U451C000	Part Number: SOS028H3U451C000	Nominal Input (V): 10 – 45	Power (W): 450	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U451D000	Part Number: SOS028H3U451D000	Nominal Input (V): 10 – 45	Power (W): 450	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U451C001	Part Number: SOS028H3U451C001	Nominal Input (V): 10 – 45	Power (W): 450	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U451D001	Part Number: SOS028H3U451D001	Nominal Input (V): 10 – 45	Power (W): 450	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U600C000	Part Number: SOS028H3U600C000	Nominal Input (V): 18 – 45	Power (W): 600	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U600D000	Part Number: SOS028H3U600D000	Nominal Input (V): 18 – 45	Power (W): 600	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Parallelable, SOSA standard keying	詳細
SOS028H3U600C001	Part Number: SOS028H3U600C001	Nominal Input (V): 18 – 45	Power (W): 600	Form-Factor: 3U	Conformal Coated: Coated	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
SOS028H3U600D001	Part Number: SOS028H3U600D001	Nominal Input (V): 18 – 45	Power (W): 600	Form-Factor: 3U	Conformal Coated: Coated + AU-plated connector	Output Voltage Config.: Programmable, VITA46 No-Key Guide Socket	詳細
